MODEL | VOLTAGE | NO-LOAD | AT MAXIMUM EFFICIENCY | STALL | |||||||
SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | ||||
| V | r/min | A | r/min | A | mN·m | Kg·cm | W | mN·m | Kg·cm | A | |
| 1.5 - 3.0 | 52 | 0.045 | 41 | 0.105 | 39.2 | 0.40 | 0.17 | 176.4 | 1.8 | 0.62 |
| Voltage | RPM |
| 1.5V | 22 |
| 2.1V | 34 |
| 2.5V | 40 |
| 2.8V | 45 |
| 3.1V | 50 |
Dimensions: Ø12 x 24 mm
Weight: 9.4g
Shaft Length: 10mm
Shaft Diameter "D" shape: Ø3 (2.5) mm
Gearbox Ratio:
RPM: 22-50
| SKU | N20G |
|---|---|
| Colour | Black |
